Gasket plate heat exchanger model list

Gasket plate heat exchanger features

Gasket plate heat exchanger mainly consists of plates and gaskets. It’s formed by a fixed frame plate and a movable plate and compressed by tightening bolts. According to different service conditions, the plate materials are mainly divided into ss304, ss316L, SMO254, titanium plate, alloy C276, etc. The gasket material is mainly EPDM, NBR and Viton gasket. The connection diameter is optional from DN32 to DN400. The hot and cold medium forms turbulent flow in the adjacent flow channels to exchange heat. Compared with the shell and tube heat exchanger, the gasket plate heat exchanger has a more compact structure and higher heat exchange efficiency.

Gasket plate heat exchanger structure

Fixed plate, movable plate, plate, gasket, tightening bolt

Gasket plate heat exchanger material

Fixed plate: Carbon steel
Movable plate: Carbon steel
Tightening bolt: Carbon steel
Plate: Stainless steel AISI304, AISI316L, Titanium, SMO254, Hastelloy C276
Gasket: NBR, EPDM, HEPDM, HNBR, VITON

Gasket plate heat exchanger advantages

1.High heat transfer efficiency: up to 8600W
2.Small space, compact structure
3.Light weight
4.Easy to maintenance, easy to clean

Gasket plate heat exchanger applications

Sulfuric acid industry, Sodium hydroxide industry, HVAC, water treatment system, swimming pool, pharmacy, beverage industry, etc.
